This post about Pinterest Listview in Android.
What is Pinterest Listview?
Display the items in multiple columns using multiple Listview on single screen.
Below i added the code for pinterest view.

Check Out This LINK  : Click here
Displaying data from two different rss feed using two listview in single screen

Activity Source Code

package com.androidbunch.pinterest.listview;

import java.util.List;

import android.app.Activity;

import android.app.ProgressDialog;

import android.os.AsyncTask;

import android.os.Bundle;

import android.view.MotionEvent;

import android.view.View;

import android.view.View.OnTouchListener;

import android.widget.AbsListView;

import android.widget.AbsListView.OnScrollListener;

import android.widget.ListView;

/**

 *

 * @author VIJAYAKUMAR M

 *

 */

public class MainActivity extends Activity  {



      private ListView listViewLeft;

      private ListView listViewRight;

      private RssReaderListAdapter leftAdapter;

      private RssReaderListAdapter rightAdapter;

      int[] leftViewsHeights;

      int[] rightViewsHeights;

      List<RssFeedStructure> rssStr ;

      List<RssFeedStructure> tam ;

      private RssReaderListAdapter _adapter;

      @Override

      public void onCreate(Bundle savedInstanceState) {

            super.onCreate(savedInstanceState);

            setContentView(R.layout.items_list);



            listViewLeft = (ListView) findViewById(R.id.list_view_left);

            listViewRight = (ListView) findViewById(R.id.list_view_right);

            RssFeedTask rss = new RssFeedTask();

            rss.execute();

            listViewLeft.setOnTouchListener(touchListener);

            listViewRight.setOnTouchListener(touchListener);

            listViewLeft.setOnScrollListener(scrollListener);

            listViewRight.setOnScrollListener(scrollListener);

      }



      // Passing the touch event to the opposite list

      OnTouchListener touchListener = new OnTouchListener() {

            boolean dispatched = false;



            @Override

            public boolean onTouch(View v, MotionEvent event) {

                  if (v.equals(listViewLeft) && !dispatched) {

                        dispatched = true;

                        listViewRight.dispatchTouchEvent(event);

                  } else if (v.equals(listViewRight) && !dispatched) {

                        dispatched = true;

                        listViewLeft.dispatchTouchEvent(event);

                  }



                  dispatched = false;

                  return false;

            }

      };



      /**

       * Synchronizing scrolling

       * Distance from the top of the first visible element opposite list:

       * sum_heights(opposite invisible screens) - sum_heights(invisible screens) + distance from top of the first visible child

       */

      OnScrollListener scrollListener = new OnScrollListener() {



            @Override

            public void onScrollStateChanged(AbsListView v, int scrollState) {

            }



            @Override

            public void onScroll(AbsListView view, int firstVisibleItem,

                        int visibleItemCount, int totalItemCount) {



                  if (view.getChildAt(0) != null) {

                        if (view.equals(listViewLeft) ){

                              leftViewsHeights[view.getFirstVisiblePosition()] = view.getChildAt(0).getHeight();



                              int h = 0;

                              for (int i = 0; i < listViewRight.getFirstVisiblePosition(); i++) {

                                    h += rightViewsHeights[i];

                              }



                              int hi = 0;

                              for (int i = 0; i < listViewLeft.getFirstVisiblePosition(); i++) {

                                    hi += leftViewsHeights[i];

                              }



                              int top = h - hi + view.getChildAt(0).getTop();

                              listViewRight.setSelectionFromTop(listViewRight.getFirstVisiblePosition(), top);

                        } else if (view.equals(listViewRight)) {

                              rightViewsHeights[view.getFirstVisiblePosition()] = view.getChildAt(0).getHeight();



                              int h = 0;

                              for (int i = 0; i < listViewLeft.getFirstVisiblePosition(); i++) {

                                    h += leftViewsHeights[i];

                              }



                              int hi = 0;

                              for (int i = 0; i < listViewRight.getFirstVisiblePosition(); i++) {

                                    hi += rightViewsHeights[i];

                              }



                              int top = h - hi + view.getChildAt(0).getTop();

                              listViewLeft.setSelectionFromTop(listViewLeft.getFirstVisiblePosition(), top);

                        }



                  }



            }

      };



       private class RssFeedTask extends AsyncTask<String, Void, String> {

                  // private String Content;

                  private ProgressDialog Dialog;

                  String response = "";

                  @Override

                  protected void onPreExecute() {

                        Dialog = new ProgressDialog(MainActivity.this);

                        Dialog.setMessage("Rss Loading...");

                       Dialog.show();

                  }

                  @Override

                  protected String doInBackground(String... urls) {

                          try {



                                String feed = "http://timesofindia.feedsportal.com/c/33039/f/533965/index.rss";

                                String tamil = "http://www.dinakaran.com/rss_Latest.asp";

                                XmlHandler rh = new XmlHandler();

                                XmlHandler rh1 = new XmlHandler();

                                rssStr = rh.getLatestArticles(feed);

                                tam = rh1.getLatestArticles(tamil);

                                response = "in";

                                } catch (Exception e) {

                              response = "out";

                                }

                        return response;

                  }

                  @Override

                  protected void onPostExecute(String result) {

                            leftAdapter = new RssReaderListAdapter(MainActivity.this,rssStr);

                              rightAdapter =new RssReaderListAdapter(MainActivity.this,tam);

                              listViewLeft.setAdapter(leftAdapter);

                              listViewRight.setAdapter(rightAdapter);

                              leftViewsHeights = new int[rssStr.size()];

                              rightViewsHeights = new int[tam.size()];

                          Dialog.dismiss();

                  }

            }

}

Adapter Source Code

package com.androidbunch.pinterest.listview;

import java.io.IOException;

import java.io.InputStream;

import java.net.HttpURLConnection;

import java.net.MalformedURLException;

import java.net.URL;

import java.util.List;

import android.app.Activity;

import android.text.SpannableString;

import android.util.Log;

import android.view.LayoutInflater;

import android.view.View;

import android.view.View.OnClickListener;

import android.view.ViewGroup;

import android.widget.ArrayAdapter;

import android.widget.Button;

import android.widget.ImageView;

import android.widget.TextView;

import android.widget.Toast;

/**

 *

 * @author VIJAYAKUMAR M

 *

 */

public class RssReaderListAdapter extends ArrayAdapter<RssFeedStructure> {

      List<RssFeedStructure> imageAndTexts1 =null;

       public ImageLoader imageLoader;

      // float imageWidth;

       Activity act;

public RssReaderListAdapter(Activity activity, List<RssFeedStructure> imageAndTexts) {

super(activity, 0, imageAndTexts);

imageAndTexts1 = imageAndTexts;

act = activity;

imageLoader=new ImageLoader(activity.getApplicationContext());

}

@Override

public View getView(final int position, View convertView, ViewGroup parent) {

Activity activity = (Activity) getContext();

LayoutInflater inflater = activity.getLayoutInflater();

View rowView = inflater.inflate(R.layout.rssfeedadapter_layout, null);

TextView textView = (TextView) rowView.findViewById(R.id.feed_text);

TextView timeFeedText = (TextView) rowView.findViewById(R.id.feed_updatetime);

Button btn = (Button) rowView.findViewById(R.id.button1);

btn.setOnClickListener(new OnClickListener() {



      @Override

      public void onClick(View v) {

            // TODO Auto-generated method stub

            Toast.makeText(act, imageAndTexts1.get(position).getTitle(), Toast.LENGTH_LONG).show();

      }

});

ImageView imageView = (ImageView) rowView.findViewById(R.id.feed_image);

        try {



            Log.d("rssfeed", "imageAndTexts1.get(position).getImgLink() :: " +imageAndTexts1.get(position).getImgLink() +" :: " +imageAndTexts1.get(position).getTitle());

            textView.setText(imageAndTexts1.get(position).getTitle());

            SpannableString content = new SpannableString(imageAndTexts1.get(position).getPubDate());

            timeFeedText.setText(content);

            if(imageAndTexts1.get(position).getImgLink() !=null){

            URL feedImage= new URL(imageAndTexts1.get(position).getImgLink().toString());

            if(!feedImage.toString().equalsIgnoreCase("null")){



            }

             else{



             }

                  }





        } catch (MalformedURLException e) {



        }

        catch (IOException e) {



        }

return rowView;

}

}



XmlHandler Source Code

package com.androidbunch.pinterest.listview;

import java.io.IOException;

import java.net.MalformedURLException;

import java.net.URL;

import java.util.ArrayList;

import java.util.List;

import javax.xml.parsers.ParserConfigurationException;

import javax.xml.parsers.SAXParser;

import javax.xml.parsers.SAXParserFactory;

import org.xml.sax.Attributes;

import org.xml.sax.InputSource;

import org.xml.sax.SAXException;

import org.xml.sax.XMLReader;

import org.xml.sax.helpers.DefaultHandler;

import android.util.Log;

public class XmlHandler extends DefaultHandler {

private RssFeedStructure feedStr = new RssFeedStructure();

private List<RssFeedStructure> rssList = new ArrayList<RssFeedStructure>();

private int articlesAdded = 0;

// Number of articles to download

private static final int ARTICLES_LIMIT = 50;

StringBuffer chars = new StringBuffer();

public void startElement(String uri, String localName, String qName, Attributes atts) {

chars = new StringBuffer();

 if (qName.equalsIgnoreCase("enclosure"))



{

       if(!atts.getValue("url").toString().equalsIgnoreCase("null")){

       feedStr.setImgLink(atts.getValue("url").toString());

       }

       else{

             feedStr.setImgLink("");

       }

}

}

public void endElement(String uri, String localName, String qName) throws SAXException {

if (localName.equalsIgnoreCase("title"))

{

      feedStr.setTitle(chars.toString());

}

else if (localName.equalsIgnoreCase("description"))

{

      feedStr.setDescription(chars.toString());

}

else if (localName.equalsIgnoreCase("pubDate"))

{

      feedStr.setPubDate(chars.toString());

}

else if (localName.equalsIgnoreCase("encoded"))

{

      feedStr.setEncodedContent(chars.toString());

}

else if (qName.equalsIgnoreCase("media:content"))



{



}

else if (localName.equalsIgnoreCase("link"))

{

      feedStr.setUrl(chars.toString());

}

if (localName.equalsIgnoreCase("item")) {

rssList.add(feedStr);

feedStr = new RssFeedStructure();

articlesAdded++;

if (articlesAdded >= ARTICLES_LIMIT)

{

throw new SAXException();

}

}

}

public void characters(char ch[], int start, int length) {

chars.append(new String(ch, start, length));

}

public List<RssFeedStructure> getLatestArticles(String feedUrl) {

URL url = null;

try {

SAXParserFactory spf = SAXParserFactory.newInstance();

SAXParser sp = spf.newSAXParser();

XMLReader xr = sp.getXMLReader();

url = new URL(feedUrl);

xr.setContentHandler(this);

xr.parse(new InputSource(url.openStream()));

} catch (IOException e) {

} catch (SAXException e) {

} catch (ParserConfigurationException e) {

}

return rssList;

}

}


items_list.xml

<?xml version="1.0" encoding="utf-8"?>

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"

    android:layout_width="fill_parent"

    android:layout_height="fill_parent"

    android:orientation="vertical"

    android:background="#FFFFFF"

    android:paddingLeft="10dp"

    android:paddingRight="10dp" >

<LinearLayout

    android:layout_width="fill_parent"

    android:layout_height="fill_parent"

    android:orientation="horizontal"

    android:background="#FFFFFF"



  >

    <ListView

        android:id="@+id/list_view_left"

        android:layout_width="fill_parent"

        android:layout_height="fill_parent"

        android:layout_weight="1"

        android:paddingRight="5dp"

        android:scrollbars="none" >

    </ListView>

<View android:layout_height="fill_parent" android:layout_width="1dip" android:background="#E4E4E4" />

    <ListView

        android:id="@+id/list_view_right"

        android:layout_width="fill_parent"

        android:layout_height="fill_parent"

        android:layout_weight="1"

        android:paddingLeft="5dp"

        android:scrollbars="none" >

    </ListView>

</LinearLayout>

</LinearLayout>


rssfeedadapter_layout.xml



<?xml version="1.0" encoding="utf-8"?>

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"

    android:layout_width="fill_parent"

    android:layout_height="wrap_content"

    android:background="#FFFFFF"

    android:padding="2dip" >

    <LinearLayout

        android:id="@+id/linearLayout1"

        android:layout_width="fill_parent"

        android:layout_height="wrap_content"

        android:orientation="horizontal"

        android:padding="5dip" >

        <ImageView

            android:id="@+id/feed_image"

            android:layout_width="wrap_content"

            android:layout_height="wrap_content"



            android:paddingRight="3dip"

            android:paddingTop="15dip" />

        <LinearLayout

            android:layout_width="fill_parent"

            android:layout_height="wrap_content"

            android:orientation="vertical" >

        </LinearLayout>

    </LinearLayout>

    <TextView

        android:id="@+id/feed_updatetime"

        android:layout_width="wrap_content"

        android:layout_height="wrap_content"

        android:layout_alignRight="@+id/feed_text"

        android:layout_below="@+id/linearLayout1"

        android:paddingBottom="3dip"

        android:paddingLeft="8dip"

        android:paddingRight="8dip"

        android:paddingTop="3dip"

        android:text="afsdfd"

        android:textColor="#A4A4A4"

        android:textSize="8dip" />

    <TextView

        android:id="@+id/feed_text"

        android:layout_width="wrap_content"

        android:layout_height="wrap_content"

        android:layout_alignLeft="@+id/linearLayout1"

        android:layout_below="@+id/feed_updatetime"

        android:maxLines="5"

        android:paddingBottom="15dip"

        android:paddingLeft="8dip"

        android:paddingRight="8dip"

        android:text="afsdfd"

        android:textColor="#000000" />

    <Button

        android:id="@+id/button1"

        android:layout_width="wrap_content"

        android:layout_height="wrap_content"

        android:layout_alignParentLeft="true"

        android:layout_below="@+id/feed_text"

        android:text="Full News" />

</RelativeLayout>
